Slipfence | Composite + Aluminum

1.

When planning your HORIZONTAL Composite SLIPFENCE installation, make sure to map out your fence posts exactly 6 feet between your posts.

2.

Dig an 8-inch diameter post hole 36 to 48 inches deep and fill the bottom with a few inches gravel if required for drainage… (colder climates may require a deeper post-hole).

3.

Insert the Square Aluminum post into the hole and ensure that the post can be set at least 76 inches from the ground to the top of the post for a 6-foot-high fence.

4.

Pour concrete into the hole around the post and adjust the post until you have at least 76 inches from the ground to the top of the post before the concrete starts to set.

5.

Next, lay one 6 foot Composite board flat on the ground for spacing between the posts. Then, do the same to set the next posts in the fence-line.

6.

While the concrete is still wet, plumb each post on both X and Y Axis. Repeat this same procedure for all posts in your fence project.

7.

When the concrete has dried, mark your first post at approximately one-and-a-half inches up from the ground level on the inside of the first post that faces the next post.

8.

Place the channel against the inside of the first post as close to center of the post as possible and sitting on top of the pencil mark. Place this channel in the center of the post (ensure it is plumb the entire length of the post), then fasten channel to the post with the Flat-head, stainless, self-drilling screws provided in the kit with a #3 Phillips drive.

9.

Once the first channel is fastened to the first post, rest the top grooved rail included in the kit on top of the first channel, and by using a speed square resting against the next post, raise the other end of the rail up to level and mark the second post on the inside with pencil… and this is the top-level mark for the second channel to be fastened to the post. Then fasten the second channel to the second post with the 4 self-drilling screws provided. You should now have two channels facing each other between two posts that are exactly level with each other.

10.

Next, measure the exact distance between posts and subtract 1/4 inch for the thickness of the channels, and with a metal blade on your miter saw, cut the bottom rail to this length. The bottom rail will then fit into channels between the posts. Insert the bottom rail that has both a tongue and a groove, with the tongue facing up horizontally inside the bottom of the channels.

11.

Then lift up one side of the bottom rail flush with the bottom of the first channel and screw in only ONE self-drilling black TEK screw through the pre-drilled hole in the channel into the bottom rail.

12.

Then lift the opposite side of the rail to be flush with the bottom of the next channel, check that the rail is level and screw this side of the rail to the channel. Check that the bottom rail is level, then proceed to screw the remaining 6 black TEK screws into the rail through the pre-drilled holes in the bottom of the channels. If on a slope and you are stepping some sections, you can either use earth dug out from post hole or shorten up the sections that are on the slope to reduce the gap between the ground and the bottom of the fence.

13.

Once all 8 screws have fastened the bottom rail to the side channels, slip in the first composite board with tongue facing up. Confirm the bottom board is level, and then repeat this process for all sections in your fence project before loading more boards in.

Confirm the measurement between posts, subtract 1/4in. for thickness of the channel and then subtract 1/2in. to determine the exact board length. Leaving 1/4in. gaps at both ends of the board inside the channels allows for thermal expansion and further reducing potential cracking or warping.

14.

After all bottom rails and bottom boards have been assembled and levelled, remeasure between posts and confirm the proper board length as described above. Proceed to slip in another 4 boards into each section in the project then come back to the first section and slip in the remaining boards in each to complete the 11-board infill. This is an important step as it will ensure all posts remain straight and plumb!

15.

Once 11 boards have been slipped into the panels and the fence looks complete, this is when you would install the Grooved Cap Rail.

16.

Same as we did for the bottom rail, measure between posts and trim the cap rail to 1/4in. less than the measurement between the insides of the posts to accommodate for the channel thickness.

17.

Slip the cap rail on top of the top board making sure it fits snug and flush with the tops of the channels and fasten with black TEK screws through the pre-drilled holes same as the bottom rail.

18.

Posts tops should sit approximately 2in. above the top of the top Cap Rail for a nice clean look. Posts can be easily cut down with a metal blade on your saw where necessary.

19.

Then tap on the “self-tightening” Aluminum Post Cap with rubber mallet to all Posts.

20.

Slipfence Gates can be added anywhere in your Slipfence project.
